breaker booms system
YZH Pedestal boom as a professional breaker booms system manufacturer and supplier in China, all the breaker booms system have passed the international industry certification standards, and you can be completely assured of quality. If you do not find your own Intent breaker booms system in our product list, you can also contact us, we can provide customized services.
The WHC880 Pedestal Rock Breaker Booms System is an XL-class, heavy-duty stationary rock breaking solution engineered for high-production mining and quarry applications. As the flagship model in YZH's WH Series, the WHC880 delivers maximum reach and power for eliminating crusher blockages at primary crushing stations. Key Features at a Glance: Boom Reach: 11,300mm horizontal / 8,960mm vertical maximum radius Rotation: 360° full rotation for complete feed zone coverage Boom Weight: 8,270 kg (without hammer) Hydraulic Hammer: Compatible with YZH1350 to YZH1400 series (large class hammers up to 175) Power Options: 55kW, 75kW, or 90kW hydraulic power unit Working Temperature: -45°C to +75°C Pedestal Size: Φ1400mm round pedestal Applications: Stationary Crushers | Grizzlies | Gyratory Crushers | High Production Mining Operations OEM/ODM Support: Custom configurations available for your specific crusher layout MOQ: 1 Set | Lead Time: Professional delivery and installation support Get a Custom Quote for WHC880
The BHB450 Portable Rockbreaker Booms System is a heavy-duty, versatile rock breaking solution engineered for medium to high-production mining and quarry applications. Designed for installation on portable or stationary crushing equipment, the BHB450 delivers impressive reach and power for eliminating crusher blockages. Key Features at a Glance: Boom Reach: 6,960mm horizontal / 4,900mm vertical maximum radius Rotation: 360° full rotation for complete feed zone coverage Boom Weight: 3,160 kg (without hammer) Hydraulic Hammer: Compatible with YZH1000 to YZH1250 series (large series up to 175 class) Power Options: 37kW, 45kW, or 55kW hydraulic power unit Working Temperature: -45°C to +75°C Pedestal Size: Φ901mm round pedestal Applications: Stationary Crushers | Grizzlies | Portable Crushing Plants | High Production Mining Operations OEM/ODM Support: Custom configurations available for your specific crusher layout MOQ: 1 Set | Lead Time: Professional delivery and installation support [Get a Custom Quote for BHB450]
The YZH BAN310 is a heavy-duty pedestal rock breaker boom system engineered for demanding mining and quarrying applications. As part of YZH's comprehensive lineup of rockbreaker solutions, the BAN310 is designed to eliminate crusher blockages, manage oversized material, and ensure continuous material flow throughout your crushing circuit. Key Features Heavy-Duty Construction: Built with high-strength steel for maximum durability in harsh mining environments 360 Rotation: Full rotational capability for comprehensive coverage of crusher and grizzly areas Hydraulic Power System: Efficient hydraulic operation for reliable breaking performance Remote Control Operation: Safe operation from a distance, keeping operators away from danger zones Extreme Climate Adaptability: Designed to operate in temperatures ranging from -45C to +75C Custom Configuration: Available with various hydraulic hammer sizes and power options to match your specific requirements
The YZH BC550 is a heavy-duty pedestal rock breaker boom system engineered for demanding mining and quarrying applications. As part of YZH's comprehensive lineup of rockbreaker solutions, the BC550 is designed to eliminate crusher blockages, manage oversized material, and ensure continuous material flow throughout your crushing circuit. Key Features Heavy-Duty Construction: Built with high-strength steel for maximum durability in harsh mining environments 360 Rotation: Full rotational capability for comprehensive coverage of crusher and grizzly areas Hydraulic Power System: Efficient hydraulic operation for reliable breaking performance Remote Control Operation: Safe operation from a distance, keeping operators away from danger zones Extreme Climate Adaptability: Designed to operate in temperatures ranging from -45C to +75C Custom Configuration: Available with various hydraulic hammer sizes and power options to match your specific requirements
Protect your most valuable assets and eliminate costly operational delays. The YZH Rockbreaker Boom System is a robust, easy-to-operate solution designed to integrate seamlessly with your jaw crusher. By instantly breaking oversized and bridged rock at the source, it prevents damaging overloads, enhances site safety, and ensures your operation runs at peak productivity.
Rockbreaker Booms Systems rake material, break material, reduce downtime, increase the productivity of your mill, insure your staff safety and keep your profits flowing in harsh and demanding applications
Since 2002, YZH has specialized in providing custom pedestal rockbreaker boom systems for mines and quarries worldwide. We combine 20+ years of engineering expertise with rigorous CE-certified quality to boost your productivity and safety through superior design. We don't just sell equipment,we deliver a partnership built on problem-solving.
