YZH Heavy-Duty Stationary Rock Breaker Booms for Tough Jobs

loading

Share to:
sharethis sharing button
YZH stationary rock breaker booms are a ful set of mining equipment for breaking oversize and hard rocks to increase efficiency and enhance safety.
Availability:
Quantity:
  • WHD1000

  • YZH

YZH Heavy-Duty Stationary Rock Breaker Booms for Tough Jobs


YZH stationary rock breaker booms are a kind of mining industrial equipment designed to improve efficiency and safety of breaking operations. The main part or YZH stationary rock breaker booms are a robust, articulated mechanical boom mounted near crushers or hoppers. Equipped with a hydraulic hammer at its end, YZH stationary rock breaker booms are engineered to handle oversized materials by breaking them into smaller, manageable fragments, ensuring a smooth flow of material through the crusher.


YZH stationary rock breaker booms can be operated remotely, which offers operators a safe and precise way to clear blockages, dislodges jammed rocks, and pre-crush hard-to-process materials. The versatility is highlighted by its ability to adapt to various angles, reach extended distances, and handle tasks requiring significant impact force, making it indispensable in mining, quarrying, and aggregate industries.


Specification of YZH Stationary Rock Breaker Booms:

Model No. Unit WHD1000
Max. horizontal working radius mm 12530
Max. vertical working radius mm 9350
Min. vertical working radius mm 4000
Max. working depth mm 7420
Rotation ° 360

pedestal boomboom system
